Servo

FS5113R 13kg 360 degree continuous rotation robot servo FS5113R 13kg Continous rotation Robot Servo

 FS5113R Standard Robot 360 Degree Continuous Rotation Servo
FS5113R RC Servo Motor Standard Robot 360 Degree Continuous Rotation Servo
 FS5113R Steering Manipulator 13kg Stall Torque Metal Gear Digital Continuous Servo For Robot Boat
Specification
Model:  FS5113R
Case:  Nylon & Fiberglass
Motor:  Coreless motor
Size:  40.8*20.1*38*49.5 mm .
weight:56g
Operating Voltage Range:  4.8-6V
No load speed:  55RPM/60°@6V
Runnig current(at no load) :  150 mA@6V
Peak stall torque":  14kg.cm@6V
Rated torque:  4.6kg.cm@6V
Stall current:  2000mA@6V
Pulse width range:  900~2100usec
Running degree:  Continuous rotation .
Direction :CCW
Operating Angle :360degree
Required Pulse :500us-2500us
Bearing Type :2BB
Gear Type :Metal
Motor Type :Carbon
Connector Wire Length :30 cm
  •  FS5113R Standard Robot 360 Degree Continuous Rotation Servo
    FS5113R RC Servo Motor Standard Robot 360 Degree Continuous Rotation Servo
     FS5113R Steering Manipulator 13kg Stall Torque Metal Gear Digital Continuous Servo For Robot Boat
    Specification
    Model:  FS5113R
    Case:  Nylon & Fiberglass
    Motor:  Coreless motor
    Size:  40.8*20.1*38*49.5 mm .
    weight:56g
    Operating Voltage Range:  4.8-6V
    No load speed:  55RPM/60°@6V
    Runnig current(at no load) :  150 mA@6V
    Peak stall torque":  14kg.cm@6V
    Rated torque:  4.6kg.cm@6V
    Stall current:  2000mA@6V
    Pulse width range:  900~2100usec
    Running degree:  Continuous rotation .
    Direction :CCW
    Operating Angle :360degree
    Required Pulse :500us-2500us
    Bearing Type :2BB
    Gear Type :Metal
    Motor Type :Carbon
    Connector Wire Length :30 cm
