Product Features:

1. The ultra-thin, subminiature

2. The full voltage input (90 ~ 264 vac)

3. Low ripple and low noise

4. Output overload short circuit protection function

5. High efficiency and power density

6. Product design to meet the EMC and safety testing requirements

7. Low power consumption, green environmental protection, no-load loss < 0.1 W

Aging and

8.100% load test

9. Meet the requirements of UL, CE,

The quality guarantee period of 10.1 years

2. Environmental conditions

The name of the project

Technical indicators:Single bit

Working temperature: - 20-60 +degree

Storage temperature: + 80-40 -degree

Relative humidity: 5-95.%

The cooling way: Natural cooling

The atmospheric pressure: 80-106Kpa

The altitude :2000M or less

vibration

Vibration coefficient of 10 ~ 500 hz, 2 g10min. / 1 cycle, 60 min. Each along the X, Y, Z axes
