Specification:
1. Input voltage range:4~38VDC(Note:input voltage not exceeding 38V)
2. Output voltage range:1.25-36VDC adjustable
3. Output current: 0-5A, recommended for use in 4.5A.
4. Output power: 75W
5.Working temperature: -40~+85 degrees
6.Operating frequency: 180KHz
7.Efficiency:96%(max)
8.Short circuit protection: yes(limit current 8A).
9.Over temperature protection
10.Input reverse polarity protection: None (if required, high current diode in series with the input).
11.L x W x H = 54 * 23 * 18mm
 12.Weight: 20g
