Features:

1.Two selectable differential input channels

2.On-chip active low noise PGA with selectable gain of 32, 64 and 128

3.On-chip power supply regulator for load-cell and ADC analog power supply

4.On-chip oscillator requiring no external component with optional external crystal

5.On-chip power-on-reset

6.Simple digital control and serial interface: pin-driven controls, no programming needed

7.Selectable 10SPS or 80SPS output data rate

8.Simultaneous 50 and 60Hz supply rejection

9.Current consumption including on-chip analog power supply regulator: normal operation < 1.5mA, power down < 1uA

10.Operation supply voltage range: 2.6 ~ 5.5V

11.Operating Temperature Range:-20 degree ~ +85 degree
