HC-SR04P Ultrasonic Ranging Sensor Module 3-5.5V Wide Ultrasonic Sensor
HCSR04 HCSR04P HC-SR04 HC-SR04P Ultrasonic Module Distance Measuring Voltage Module Sensor Module For Arduino 3V-5.5V
HC-SR04P SR04 Ultrasonic Sensor HC-SR04 Measuring Distance Sensor LED Display Module Robot MCU
HC-SR04P Ultrasonic Module 3-5.5V Distance Measuring Sonar Sensor Board
HC-SR04-P is a wide range of ultrasound working voltage measuring module distance. Module size and software is fully compatible with the old HC-SR04 version. It can be perfectly interrupted with the old HC-SR04 version.
Low to 3V minimum operating voltage, so that it can be directly connected to the 3.3V powerMCU.
Feature
High operating voltage: 3 V-5.5 V
With software and hardware HC-SR04 size is fully compatible
Detection distance:
5 V: 2 cm-450 cm
3.3 V: 2 cm to 400 cm
Detection angle: <15
Use of industrial grade MCU, operating temperature: -20-80 degrees Celsius
Note:
1: This module does not have to be charged connection, if you want to live connection, then let the Gnd module end connection first. Otherwise it will affect the form‘s work.
2: When they go, the area of the measured object is not less than 0.5 square meters, and to be as easy as possible.
3: If the test surface is irregular or remote test objects, multiple measurements can be used to correct it.
