characteristic
Supply voltage: 1.95 V to 3.6 V
Interface voltage: 1.6 V to 3.6 V
± 2g / ± 4g / ± 8g dynamically selectable range
The output data rate (ODR) Range: 1.56 Hz to 800 Hz
Noise: 99μg / √Hz
12-bit and 8-bit digital output
I2C digital output interface (when the pull-up resistor is 4.7 kΩ, the highest frequency up to 2.25 MHz)
Suitable for six interrupt sources two programmable interrupt pin
3 embedded motion detection channel
Freefall or motion detection: 1 channel
- Pulse detection: 1 channel
- Shake detection: 1 channel
Set with lag compensation direction (horizontal / vertical) detection
Automatic and automatic wake sleeping ODR can automatically change
High-pass filtered data can be output in real time
Self-Test
RoHS compliant
Power: 6 μA - 165 μA
