Sensor Module

< >

Photosensitive Brightness Resistance Sensor Module Light Intensity Detect Resistor Module Diy Kit 4PIN LM393

LM393 Optical Sensitive Resistance Light Detection Photosensitive Sensor Module DIY Kit school education lab

Photosensitive Brightness Resistance Sensor Module Light Intensity Detect Resistor Module Diy Kit 4PIN LM393

LM393 4pin Optical Sensitive Resistance Light Detection Photosensitive Sensor Module DIY Kit

Photosensitive Brightness Resistance Sensor Module Light Intensity Detect Photosensitive Resistor Module

LM393 Optical Sensitive Resistance Light Detection Photosensitive Sensor Module DIY Kit school education lab

Photosensitive Brightness Resistance Sensor Module Light Intensity Detect Resistor Module Diy Kit 4PIN LM393

LM393 4pin Optical Sensitive Resistance Light Detection Photosensitive Sensor Module DIY Kit

Photosensitive Brightness Resistance Sensor Module Light Intensity Detect Photosensitive Resistor Module

1 photosensitive resistance module‘s most sensitive to ambient light, commonly used to detect environment around the

brightness of the light, or MCU trigger relay module, etc.;

2module in the environment light intensity than set threshold, output high level DO end, when the environment light intensity more than set threshold, the DO output low level;

3 the DO output can be directly connected to microcontroller, through single chip microcomputer to detect the high and low level, thus to detect the environment light intensity change;

4 the DO output can be directly driven our relay module, which can form a light-operated switch.

1 Using photosensitive resistance sensor sensitive type;

2 Working Voltage:3.5V-5V;

3 Output form:Digital Switch show (0 and 1);

4 Fixed Bolt Hole,easy installation;

5 Small PCB size:3.2CM*1.7CM;

6 the comparator output, signal clean, good waveform, driving ability is strong, for more than 15 ma;

7 with adjustable potentiometer to adjust light brightness;
