Sensor Module

AMT1001 type analog voltage output resistance temperature and humidity sensor module integrated temperature compensation

AMT1001 type analog voltage output resistance temperature and humidity sensor module integrated temperature compensation
AMT1001 Resistive Humidity Module Humidity Sensor Humidity Probe
New AM1001 AMT1001 4.5V-5.5V Resistive Temperature And Humidity Sensor Module Probe
DC5V Resistive Temperature Humidity Sensor Probe AMT1001 0-60 Degrees Thermistor
Description:
1. Low power
2. small volume
3. with temperature compensation
4. single-chip calibration linear output
5. high reliability
6. easy to use
7. inexpensive
  • AMT1001 type analog voltage output resistance temperature and humidity sensor module integrated temperature compensation
    AMT1001 Resistive Humidity Module Humidity Sensor Humidity Probe
    New AM1001 AMT1001 4.5V-5.5V Resistive Temperature And Humidity Sensor Module Probe
    DC5V Resistive Temperature Humidity Sensor Probe AMT1001 0-60 Degrees Thermistor
    Description:
    1. Low power
    2. small volume
    3. with temperature compensation
    4. single-chip calibration linear output
    5. high reliability
    6. easy to use
    7. inexpensive
    Feature:
    supply voltage (Vin): DC5V ± 5%
    Current Consumption: 2mA (MAX 5mA)
    Operating temperature range: 0 to 60 ° C
    Humidity range: 95% RH (non condensing)
    Humidity measuring range: 20 to 95% RH
    Storage temperature range: 0 to 60 ° C
    Storage humidity range: 95% RH (non condensing)
    Humidity measurement accuracy: ± 5% RH (condition: at25 ℃)
    The standard humidity output voltage: (conditions: at25 ℃, Vin = 5.0V)
    Relative humidity（%RH）     20     30     40     50     60     70     80
    Output voltage(V)     0.6     0.9     1.2     1.5     1.8     2.1     2.4
    The temperature detection characteristics: ± 5% R (25 ℃) = 10Kω ± 5%
    Temperature dependencies (11) (Reference): ± 5% RH (Vin = 5.00V DC ,40-80% RH,25 ℃ as the reference range of,0-50 ℃)
    Voltage dependence (12) (Reference): ± 5% RH (at25 ° C 40 - 80% RHDC5V benchmark,4.75-5 .25 V range)
    Application:
    Air conditioners
    Humidifiers
    Dehumidifiers
    Communication
    atmospheric environmental monitoring
    industrial process control
    agriculture
    measuring instruments
