Introduction:
The Prototype development module is designed specifically for the Raspberry Pi. The module suitable enthusiasts and user
can weld peripheral to the module; The module expand some amphenol connector and some SMT, so the user can finish
prototype test easily.
Feature:
Expand common GPIO through amphenol connector
Expand common GPIO through Female Header Connector
Set aside a large amount of welding hole
Port:
I2C amphenol connector
Female Header Connector
SPI amphenol connector
SPI Female Header Connector
Serial port amphenol connector
Serial port Female Header Connector
3.3V Vcc
5V Vcc
Product Parameters:
3.5mm Amphenol Connector
2.54mm Female Header Connector
Typical Application:
Hardware weld primer
Prototype experiment
DIY enthusiasts
How to use:
Insert the Prototype development module to Raspberry Pi, pay attention don’t make the direction reversed! The correct
direction of insert module is above the Raspberry Pi’s PCB.
Package list:
1 x Prototyping Expansion Shield
